class: middle, right
# Categories and Arrows:<br/>What Do They Do? Do They Do Things??<br/>Let's Find Out!
.footnote[A massively informal introduction to what makes arrows arrows]
---
# What is an Arrow?
In category therory, an arrow, is... well... an arrow in a diagram. Mostly.
Official definition: _stuff that maps other stuff to moar stuff_ (ie. a morphism).
...yeah, ask Arnaud or Krzysztof about that really...
---
# What is an Arrow _in Haskell_?
As is usual in Haskell, an ungodly mess of typeclasses, I'm afraid.
#### In a nutshell:
```haskell
data A x y -- `Type -> Type -> Type` kind
```
An arrow is a computation from `x` to `y` with... some effects. And you can
compose them to build a pipeline of computations.
#### The Arrow typeclass stack:
```haskell
-- From most OK to least OK:
class Category -- We're cool
class Arrow -- Oh wowie! Parallel composition, still cool
class ArrowZero -- Mostly chill
class ArrowPlus -- Hmmm, okaaayyy...
class ArrowLoop -- Oh, some Tardis-trickery, I can deal with it I guess...
class ArrowChoice -- Wait, we're /branching/ now? But I thought
-- we were making a static pipeline of...
class ArrowApply -- PINEAPPLE! PINEAPPLE!
```
---
# Preliminary Warning
Rather: use monads directly. They're cool.
---
# A general form for Arrows
#### Not the _MOST_ general form, but still a general and useful one:
```haskell
newtype ArrowFromEffects f w m a b =
ArrowFromEffects (f (w a -> m b))
```
- `f`: Applicative
- `w`: Comonad
- `m`: Monad
- `w` and `m`: Distributive (ie. `w (m a) -> m (w a)`)
- Then: `ArrowFromEffects f w m` is `Arrow`, yay
And if `f`, `w` and `m` are just `Identity`, then we just have... a pure function.
#### Decomposing that gives:
```haskell
newtype Kleisli m a b = Kleisli (a -> m b) -- from base
newtype Cokleisli w a b = Cokleisli (w a -> b) -- from comonad
newtype Tannen f arr a b = Tannen (f (arr a b)) -- from bifunctors
```
Each implements all the classes up to `ArrowChoice`
---
# Composing Arrows
#### Product
```haskell
type Product arr arr' a b = (arr a b, arr' a b)
```
`arr` and `arr'` fully parallel. Cannot communicate. Implements whatever classes
`arr` and `arr'` both implement.
#### Alternation
```haskell
data Altern arr arr' a b where
AlternId :: Altern arr arr' a a
Altern :: arr a x -> arr' x y -> Altern arr arr' y b -> Altern arr arr' a b
```
Can communicate. Implements at least Category and Arrow (didn't try the rest
yet. Also didn't check if it satisfies Arrow laws yet (Booooo me, yes I know))
---
# Free Arrows
Create an arrow out of a `eff :: Type -> Type -> Type` datatype which doesn't
have to implement anything:
#### Initial encoding
```haskell
data FreeArrow eff a b where
Id :: FreeArrow eff a a
Arr :: (a -> b) -> FreeArrow eff a b
Eff :: eff a b -> FreeArrow eff a b
Comp :: FreeArrow eff a b -> FreeArrow eff b c -> FreeArrow eff a c
First :: FreeArrow eff a b -> FreeArrow (a,c) (b,c)
```
#### Final ~~countdown~~ encoding
```haskell
type FreeArrow eff a b =
forall ar. (Arrow ar) => (forall x y. eff x y -> ar x y) -> ar a b
```
---
# Summary
- Kleisli (used in `funflow`)
- Cokleisli
- Tannen (used in `porcupine`)
- Product (to be used in `porcupine`)
- Alternation
- Free arrows (used in `funflow`)
### Do these cover all the ways to define an arrow?
Let's say that's left as an exercise to the reader :) (Pheeewww...)
### What about that "profunctor" cr*p I hear about?
`Arrow` = `Category` ∩ `Profunctor` ∩ `Strong` ∩ `arr` method
but these aren't all in `base` for now.
---
# What was the point?
```haskell
newtype ArrowFromEffects f w m a b =
ArrowFromEffects (f (w a -> m b))
```
An arrow is the combination of monadic, comonadic and applicative
effects, or some parallel/sequential combination of that, itself possibly
wrapped in an applicative. Pretty general a framework.
_**Arrow = computation with ahead-of-time effects (applicative) and just-in-time
effects (monadic)**_
Defining applicative and monadic effects easy: lots of them around, lots of libraries.
Decomposing applicative effects as separate types (to `Compose` them) clean and
easy.
Use of comonadic effects? ...Could come handy. Dunno, still processing, some
papers to read and all.
### IMHO: Very relevant for code decomposition and reusability
---
# Comparison with Applicative
_In case of no monadic effects_, one could argue that:
```haskell
type Arr a b = f (a -> b)
```
Same power? Do we _really_ need arrows? (= Couldn't we have an equivalent for
every class this way?)
### Let's try to implement the Arrow stack with that type:
```haskell
class Category -- Yup
class Arrow -- Yup
class ArrowZero -- Alternative is there, so yup
class ArrowPlus -- Yup, for same reasons
class ArrowLoop -- Oh, oh, wait, wait, is it... and yes that's a yup
class ArrowChoice -- Yes... Aaaand dammit, no, it doesn't have the right semantics
class ArrowApply -- Lol
```
`ArrowChoice` doesn't have the right semantics (though it satisfies Arrow
laws!): you can't shortcut effects.
---
# Comparison with Applicative (2)
### Wait! Now we have `Selective`!!
...Yeah. Still no ArrowChoice, sorry...
```haskell
branch :: (Selective f)
=> f (a -> c) -> f (b -> d) -> f (Etiher a b) -> f (Either c d)
(|||) :: (ArrowChoice arr)
=> arr a c -> arr b d -> arr (Either a b) (Either c d)
```
If `arr` is `f (a -> b)` that gives:
```haskell
branch :: f (a -> c) -> f (b -> d) -> f (Etiher a b) -> f (Either c d)
(|||) :: f (a -> c) -> f (b -> d) -> f (Either a b -> Either c d)
```
`(|||)` with `(<*>)` gives you `branch`, but no way back possible.
#### Every `ArrowChoice` can give you a `Selective`, but not the reverse :/
---
# Case of `funflow`
One of most important functions:
```haskell
step' :: Properties a b -> (a -> b) -> Flow a b
```
Generalization of `arr` function
Could have been:
```haskell
step' :: Properties a b -> (a -> b) -> AppFlow (a -> b)
```
(thus generalizing `pure`)
But what about:
```haskell
stepIO' :: Properties a b -> (a -> IO b) -> Flow a b
```
No way to return a `f (a -> b)` from a `(a -> m b)`!!
